Near series-production S-Class technology vehicle with plug-in hybrid
The luxury class on the road to the three-litre car
Shortly after the successful market launch of the S 400 HYBRID, currently the most fuel-efficient luxury-segment saloon with a petrol engine, Mercedes-Benz will be presenting the first “three-litre car” in the premium class – the Vision S 500 Plug-in HYBRID – at the 63rd IAA in Frankfurt. The technology vehicle will display the future of Mercedes-Benz’ modular set of hybrid systems. The Vision S 500 Plug-in HYBRID can drive for up to 30 kilometres solely on electricity and therefore without producing any local emissions. The efficient drive system combined with the CO2 bonus for the battery-electric driving mode enables the vehicle to achieve a certified consumption of only 3.2 litres of petrol per 100 kilometers. With CO2 emissions of only 74 grams per kilometre in the NEDC (New European Driving Cycle), the experimental vehicle developed in Sindelfingen demonstrates the long-term viability of future S‑Class generations. The outstanding values are made possible by the combination of a plug-in hybrid with the efficiency-boosting BlueEFFICIENCY measures. At the same time, the Vision S 500 Plug-in HYBRID has all of the strengths that are typical of the S‑Class: top comfort, outstanding safety and masterful performance. The drive system in the concept car consists of three main components: a powerful V6 petrol engine with a next-generation direct injection system, a 44 kW/60 hp hybrid module and a lithium-ion battery with more than 10 kWh of storage capacity that can be recharged at charging stations. The Vision S 500 Plug-in HYBRID accelerates from 0 to 100 km/h in 5.5 seconds.
“The Vision 500 Plug-in HYBRID is a new milestone on our path toward zero-emission mobility,” says Dr. Dieter Zetsche, Chairman of Daimler AG and Head of Mercedes-Benz Cars. “It is a luxurious and safe S‑Class that offers superior driving performance while at the same time consuming less fuel than current compacts. All of this shows that our top models will also be able to combine automotive fascination with responsibility for the environment.”
“Although it will take some time before this model can go into series production, our engineers will be working full steam to carry out the necessary integration measures and ensure that all components can meet the tough everyday demands required of a luxury long-distance saloon,” says Dr. Thomas Weber, member of the Board of Management of Daimler AG with responsibility for Group Research and Mercedes-Benz Cars Development. “We’ve already got all the key technology we need for such a dream car, which is why I see it being included in the next generation of the S‑Class. The important thing now is that our development work be accompanied by the establishment of a full-coverage infrastructure that will allow the potential of this innovative drive system to be fully exploited.”
S 500 Plug-in HYBRID is basically the same as that for the S 400 HYBRID. One system-specific attribute is the presence of an additional clutch integrated between the combustion engine and the electric motor. This device decouples the two components in the pure electric drive mode, thereby ensuring the highest level of efficiency in the latter. Moreover, because it is fully integrated into the vehicle’s converter housing, the clutch does not take up any additional space.
Electrical outlet as a filling station: Powerful plug-in battery
Range of up to 30 kilometres with all-electric driving
Extensive electronic safety and control components
On the road to plug-in hybrids: Diesel-hybrid concepts
Combustion engine (petrol)
Performance and fuel consumption
